G&D DVI-CPU User Manual

Console module »DVI-CON-Video«
Computer and console modules · 171
Installation
Connecting the console devices
DVI/VGA Out: Connect the monitor/projector of the local console.
Micro In: Connect the optional microphone of the local console.
Speaker: Connect the optional speakers of the local console.
LED Out: If you expanded the functional range of the matrix switch by purchasing the
TradeSwitch feature, connect the optional TS-LED to this interface.
Connection to the matrix switch
Transmission: Use a category 5e (or better) twisted pair cable to connect the Transmis-
sion interface to a Dynamic Port (RJ45) of the matrix switch.
ADVICE: You can also connect the console module directly to a compatible computer
module.
Transmission
DVI/VGA Out
Micro In
Speaker
Red. Power
Main Power
LED Out
T
ransm
i
ss
i
o
n
R
e
d
.
P
ower
M
a
i
n
P
ower
Transmission
DVI/VGA Out
Micro In
Speaker
Red. Power
Main Power
LED Out
DVI
/
V
G
A
O
u
t
Mi
cro
In
Sp
eake
r
R
e
d
.
P
ower
M
a
i
n
P
ower
LED
O
u
t

G&D DVI-CPU Specifications

General

Brand	G&D
Model	DVI-CPU
Category	Control Unit
Language	English
