Console module »DVI-CON-2«
126 · Computer and console modules
Technical data
DVI-CON-2
Interfaces to
console
Video: 1 × DVI-I (DVI Single-Link or VGA)
Keyboard/mouse signals 2 × PS/2 socket
3 × USB-A
Audio: 2 × 3.5 mm jack socket
Tradeswitch-LED: 1 × D-SUB 9 scoket
Data transmission to
counterpart
Interface: 2 × RJ45 socket
Transmission length: Max. 140 meters
Video Max. resolutions: 1920 × 1200@60Hz
1280 × 1024@85Hz
Further VESA and CTA standardized
resolutions within the video
bandwidth and horizontal/vertical
frequency possible.
Colour depth: 24 bits
Pixel rate: 25 MHz to 165 MHz
Vertical frequency: 50 Hz to 180 Hz
Horizontal frequency: 30 kHz to 130 kHz
DDC/CI: The device supports monitors with a
DDC/CI function. The DDC information
are transparently forwarded to the moni
-
tor to support a maximum number of
monitors. However, the support cannot
be guaranteed for all monitor models.
Audio Transmission type: transparent, bidirectional
Resolution: 24 Bit
Sampling rate: 96 kHz
Bandwidth: 22 kHz
Main power supply Type: Internal power pack
Connection: 1 × IEC plug (IEC-320 C14)
Power input: 100 - 240 VAC; 0.3 A - 0.2 A
Redundant
power supply
optional
Type: Portable power pack (12 V/2 A)
Connection: 1 × Mini-DIN 4 socket (Power In)
Power input: 1.2A @ 12 VDC
Casing Material: Anodised aluminium
Dimensions (W × H × D): Approx. 210 × 44 × 210 mm
Weight: Approx. 1.26 kg
