G&D DVI-CPU User Manual

Console module »DVI-CON-Fiber-MC2«
140 · Computer and console modules
Power supply
Main Power: Connect the supplied power cable. Insert the cable’s Schuko plug in a
power socket.
Red. Power: Connect the connection cable of a compatible power pack to provide the
console module with a second, redundant power supply.
Startup
Turn on the console module after its installation.
Use the Main Power power pack or a redundant power pack to establish the power
supply:
 Turn on the Main Power power pack.
 Use an optional power pack to supply the Red. Power socket with power.
Main Power
LED Out
DVI/VGA Out 1
DVI/VGA Out 2
Transmission 1
Transmission 2
Red. Power
Mouse
Keyb.Micro In
Speaker
Generic
Keyb./Mouse
