Console module »U2-R-CON«
192 · Computer and console modules
Status displays
The blinking Transmission LEDs show the following connection statuses:
Technical data
LED Colour Status Meaning
Left Yellow Off No connection to network.
On A console module is accessing the computer module.
Right Green On A console module is accessing the computer module.
Blinking No communication with the counterpart.
Flashing Connection to the counterpart established successfully.
No console module is accessing.
U2-R-CON
Interfaces to
target computer:
USB 2.0: 4 × USB-A
RS232: 1 × D-SUB 9 socket
Data transmission to
counterpart
Interface: 1 × RJ45 socket
Transmission length: Max. 140 metres
USB 2.0 Transmission type: Transparent
Transmission rate: Max. 480 Mbit/s
RS232 Transmission type: Transparent
Transmission rate: Max. 115.200 bit/s
Signals: RxD, TxD, RTS, CTS, DTR, DSR, DCD
Main power supply Type: Portable power pack
Connector: 1 × Mini-DIN 4 socket
Power consumption: 1.5A @ 12 VDC
Housing Material: Anodised aluminium
Dimensions (W × H × D): Approx. 105 × 26 × 104 mm
Weight: Approx. 0.24 kg
Operating
environment
Temperature: +5 °C to +40 °C
Air humidity: 20 % to 80 %, non-condensing
Storage
environment
Temperature: -20 °C to +60 °C
Air humidity: 15 % to 85 %, non-condensing
Conformity CE, EAC, FCC Class B, RoHS
