G&D DVI-CPU User Manual

Computer module »DL-DVI-CPU-Fiber-UC«
56 · Computer and console modules
Technical data
DL-DVI-CPU-FIBER-UC
Interfaces to
computer
Video: 1 × DVI-D (Dual Link)
Keyboard and mouse signals 1 × PS/2 socket
1 × USB-B
Audio: 2 × 3,5 mm jack plug
Data transmission to
counterparts
Interface: 2 × LC-Duplex socket
Transmission distance:  DL-DVI-CPU-Fiber-UC(M)
Max. 100 Meter (62,5μ/125μ),
Max. 200 Meter (50μ/125μ OM2)
Max. 400 Meter (50μ/125μ OM3)
 DL-DVI-CPU-Fiber-UC(S)
Max. 5.000 Meter (9μ/125μ OS1)
 DL-DVI-CPU-Fiber-UC(S+)
Max. 10.000 Meter (9μ/125μ OS1)
Video Format: DVI-D (Dual Link)
Colour depth: 24 bit
Video bandwidth: 25 to 330 MP/s
Examplary resolutions:  2560 × 1600 @ 60 Hz
 2048 × 2160 @ 60 Hz
 2048 × 2048 @ 60 Hz
 1920 × 1200 @ 60 Hz
 1280 × 1024 @ 85 Hz
 3840 × 2160 @ 30 Hz
 4096 × 2160 @ 30 Hz
 640 × 480 @ 60 Hz
 Further VESA and CTA standardized
resolutions within the video
bandwidth and horizontal/vertical
frequency possible.
Vertical frequency: 24 Hz to 120 Hz
Horizontal frequency: 25 kHz to 185 kHz
DDC/CI: The device supports monitors with a
DDC/CI function. The DDC information
are transparently forwarded to the moni
-
tor to support a maximum number of
monitors. However, the support cannot
be guaranteed for all monitor models.
Audio Transmission type: transparent, bidirectional
Resolution: 24 Bit
Refresh rate: 96 kHz
Bandwidth: 22 kHz
