Computer module »DVI-I-CPU-UC«
74 · Computer and console modules
Technical data
DVI-I-CPU-UC
Interfaces to
computer:
Video: 1 × DVI-I
Keyboard and mouse signals: 2 × PS/2 socket
1 × USB-B
Audio: 2 × 3.5 mm jack socket
Data transmission
to counterparts
Interface: 2 × RJ45 sockets
Transmission length Max. 140 metres
Video Max. resolution (digital): 1920 × 1200 @ 60 Hz
Further VESA and CTA standardized
resolutions within the video
bandwidth and horizontal/vertical
frequency possible.
Resolutions (analog): 640 × 350 @ 60-120 Hz
640 × 400 @ 50-120 Hz
640 × 480 @ 50-120 Hz
720 × 400 @ 50-120 Hz
800 × 600 @ 50-120 Hz
1024 × 768 @ 50-120 Hz
1152 × 864 @ 50-85 Hz
1152 × 900 @ 50-76 Hz
1280 × 720 @ 50-85 Hz
1280 × 768 @ 50-100 Hz
1280 × 960 @ 50-75 Hz
1280 × 1024 @ 50-75 Hz
1360 × 768 @ 50-85 Hz
1400 × 1050 @ 50-75 Hz
1440 × 900 @ 50-85 Hz
1600 × 1200 @ 60 Hz
1680 × 1050 @ 60 Hz
1920 × 1080 @ 60 Hz
1920 × 1200 @ 60 Hz
Colour depth: 24 bits
Pixel rate: 25 MHz to 165 MHz
Vertical frequency: 24 Hz to 120 Hz
Horizontal frequency: 25 kHz to 135 kHz
DDC/CI: The device supports monitors with a
DDC/CI function. The DDC information
are transparently forwarded to the moni
-
tor to support a maximum number of
monitors. However, the support cannot
be guaranteed for all monitor models.
Audio Transmission type: transparent, bidirectional
Resolution: 24 bits
Sampling rate: 96 kHz
Bandwidth: 22 kHz
