GAT ECO.Side Lock 7010 (NW) F/ISO
Commissioning
www.gantner.com HB_GAT-ECOSide-Lock7010-FISO--EN_11 37
4.4 Automatic Antenna Adjustment
The antenna of the GAT ECO.Side Lock 7010 F/ISO must be calibrated to ensure the optimal reading range for the
RFID data carriers. To complete this calibration, the lock is equipped with an automatic antenna adjustment function
that is activated using the SERVICE data carrier or via GAT Config Manager.
4.4.1 Antenna Adjustment using the SERVICE Data Carrier
The SERVICE data carrier is included in the GAT ECO.Basic Set F/ISO (see “5.3 GAT ECO.Basic Set F/ISO”).
Complete the following steps to activate the antenna adjustment function.
► Press the locker door shut with one hand.
► Hold the SERVICE data carrier next to the RFID reading field. Remove the data carrier immediately after
activating the antenna adjustment.
o The antenna adjustment process begins and the status LED flashes red for 5 seconds. The process
is complete when the LED flashes green for 1 second and the lock emits a tone signal.
It is possible to activate the antenna adjustment function even when the locker door is locked.
4.4.2 Antenna Adjustment via GAT Config Manager
► While configuring the GAT ECO.Side Lock 7010 F/ISO in GAT Config Manager
(see “5 CONFIGURATION”), click on the “Antenna Adjustment” button.
► Disconnect the USB cable from the lock and close the locker door. After disconnecting the USB cable, you
must close the door within 15 seconds to activate the function.
o The antenna adjustment process begins and the status LED flashes red for 5 seconds. The process
is complete when the LED flashes green for 1 second and the lock emits a tone signal.
For locks with older firmware versions, the time limit to activate the function after disconnecting the USB cable
is 7 seconds.
