Commissioning
48 HB_GAT-ECOSide-Lock7010-FISO--EN_11 www.gantner.com
Options
Description
Format
Default
Reader
RF Standards
ISO 15693
If “True”: ISO 15693 data carriers can be read by the lock.
Boolean
False
ISO 14443A
If “True”: ISO 14443 (MIFARE) data carriers can be read by
the lock. This setting is not configurable
Boolean
False
Segment configuration
General
Site key
Site key of the device. All data carriers must have the
same site key to be used with the device.
Hex
9999
Key set
DESFire AES Keys, encrypted
Hex
MIFARE Classic
Options for reading MIFARE Classic data carriers
Sector Num
The segment where UID data is stored
Integer
4
Read Key
Select the Read Key (Key A or Key B)
List option
Write Key
Select the Write Key (Key A or Key B)
List option
MIFARE DESFire
Options for reading MIFARE DESFire data carriers
Read Key Num
Number of the read key
Integer
Write Key Num
Number of the write key
Integer
Application ID
ID of the target DESFire application
Text
Encryption Mode
Select the type of encryption mode
List option
File Num
File number to read data from
Integer
File Comm Mode
File communication mode: “Plain”, “Maced”, “Enciphered”
List option
File Type
Type of file: “Standard” , “Backup”
List option
ISO 15693
Options for reading ISO 15693 data carriers
General Block Num
The segment where general data is stored
Integer
13
Certificate Block Num
The segment where certificate data is stored
Integer
15
Locker Block Num
The segment where locker data is stored
Integer
19
Gantner.Connect
Field
ID number for Gantner.Connect.
Integer
1
Application
Master cards
Master Card 1 - 10
Fields to enter number for master card 1 to 10
Integer
Licencse
License CertificateCheck
When "installed" is displayed here, the certificate check
can be switched on/off
Info
CertificateCheck enabled
Switch on/off the certificate check for data carriers
Boolean
False
Read only parameter
Production
Article Num
Article number of the device
Integer
Serial Num
Serial number of the device
Integer
Manufacturer Num
Manufacturer number of the device
Integer
Production Year
Production year of the device
Integer
Production Week
Production week of the device
Integer
HardwareUIDNum
Unique ID number of the hardware
Integer
Controller Type
Controller type of the device
Hardware Vers
Hardware version of the device
Integer
Bootloader Vers
Bootloader version of the device
Integer
Firmware Vers
Firmware version of the device
Integer
LockEngineVers
Lock logic version of the device
Integer
Table 5.1 – Configuration settings for the GAT ECO.Side Lock 7000 BA in GAT Config Manager
