Use and maintenance instruction
Rev. 01/14 - ENG (original)
Via Leonardo da Vinci, 32/B
36034 Malo (VI) Italia
9
EXCAVATOR “A-TRACTION”
T E Z A
1.8 TECHNICAL DATA
Motor Honda 390 GX 13 HP (Honda 270 GX 9 HP)
Fuel supply Unleaded petrol
Digging depth Cm. 60 - 80
Digging width 11 - 13 - 16 cm slotted chin or mixed chain (holes and spikes)
Digging width 10 - 12 cm spiked chain
Transmission to the Crawler chain Hydraulic
Speed during operation from 0 at 0,3 km/h
Speed during transfer from 0 at 2 km/h
Moving material (lateral) by means of the screw
Crawler chain in rubber cm 180 x 60 x 28
Weight (in normal running order) kg 300
Maximum slope for operational ability (both uphill and downhill) 10%
Maximun side slope 5%
Tools spiked for compact soils , slotted for loose material, or mixed solutions
