Gardena SILENO minimo User Manual

8. Remove the battery.
9. Disconnect the cable to the battery.
10. Connect the cable to a new battery.
11.
Put the new battery into position in the product.
12. Install the battery holder and the screw.
13. Remove the sealing strip in the upper chassis.
14. Install a new sealing strip in the upper chassis. Put
one end of the sealing strip in line with the mark on
the chassis.
CAUTION: Install a 5 mm sealing
strip. An incorrect dimension of the
sealing strip or an incorrect installation
can cause leakage.
15. Put the sealing strip clockwise around the lower
chassis.
16. Put the other end of the sealing strip above the first
end and then out of the channel.
17. Attach the sealing strip in the retainer.
18.
Install the upper chassis and attach the 10 screws
(Torx 20).
5.7 Winter service
Take your product to your GARDENA service for service
prior to winter storage. Regular winter service will
maintain the product in good condition and create the
best conditions for a new season without any
disruptions.
Service usually includes the following:
• Thorough cleaning of the body, the chassis, the
blade disc and all other moving parts.
• Testing of the product’s function and components.
• Checking and, if required, replacing wear items
such as blades and bearings.
• Testing the product’s battery capacity as well as a
recommendation to replace battery if necessary.
• If new firmware is available, the product is
updated.
30 - Maintenance 1585 - 002 - 08.12.2020

Gardena SILENO minimo Specifications

General

Type	Robotic lawn mower
Noise level	57 dB
Cutting width	160 mm
Grass catcher	-
Product color	Black, Blue
Maximum lawn area	250 m²
Maximum cutting height	45 mm
Minimum cutting height	20 mm
International Protection (IP) code	IPX5
Power source	Battery
Charging time	1.25 h
Power consumption per month (max)	2.1 kWh

Weight and Dimensions

Depth	520 mm
Width	340 mm
Height	220 mm
Weight	6100 g
