Garland MWG3W Operating Instructions

ГАЗОВЫЕ И ЭЛЕКТРИЧЕСКИЕ ГРИЛИ-«РАКУШКИ» GARLAND С СИСТЕМОЙ РАСПОЗНАВАНИЯ ПРОДУКТА
АРТ. № 4521777 (11/07/08)10
SPECIFICATIONS
SUPPLY
TOTAL kW
LOAD
LOADING: (kW/PHASE)
NOMINAL AMPS PER LINE
MENNEKES
PLUG REQUIRED
230V / 400V 230V / 400V
3N~ 400V
50Hz
22.7
L1/L2 L1/L3 L2/L3 L1 L2 L3
7.60 7.60 7.60 33.0 33.0 33.0 Type 748
(1) 50-AMP
CIRCUIT
TOTAL
kW
LOAD
LOADING: (kW/PHASE)
NOMINAL AMPS PER LINE
NEMA
RECEPTACLE
REQUIRED
208V / 220V / 240V 208V / 60Hz 240V / 60Hz
L1/L2 L1/L3 L2/L3 L1 L2 L3 L1 L2 L3
22.95 7.65 7.65 7.65 63.9 63.9 63.9 55.2 55.2 55.2 15-50R
INTERLOCK HVAC Hood / Fire Suppression Interlock Circuit: 7 Amps / 120V / Single Phase L21-20R
Input Specications, ELECTRIC Grills, Canada:
(2) 50-AMP
CIRCUITS &
INTERLOCK
TOTAL
kW
LOAD
LOADING: (kW/PHASE)
NOMINAL AMPS PER LINE
NEMA
RECEPTACLE
REQUIRED
208V / 220V / 240V 208V / 60Hz 220V / 60Hz 240V / 60Hz
L1/L2 L1/L3 L2/L3 L1 L2 L3 L1 L2 L3 L1 L2 L3
INPUT 1 7.65 2.55 2.55 2.55 21.3 21.3 21.3 20.1 20.1 20.1 18.4 18.4 18.4 15-50R
INPUT 2 15.30 5.10 5.10 5.10 42.6 42.6 42.6 40.2 40.2 40.2 36.8 36.8 36.8 15-50R
INTERLOCK HVAC Hood / Fire Suppression Interlock Circuit: 7 Amps / 120V / Single Phase L21-20R
Input Specications, ELECTRIC Grills, United States:
Input Specications, ELECTRIC Grills, CE Approved Models MWE3W-CE, MWE3S-CE:
SUPPLY
TOTAL kW
LOAD
LOADING: (kW/PHASE)
NOMINAL AMPS PER LINE
MENNEKES
PLUG REQUIRED
230V / 400V 230V / 400V
L1/L2 L1/L3 L2/L3 L1 L2 L3
220V 50Hz 22.7 7.60 7.60 7.60 34.5 34.5 34.5
Type 748
240V 50Hz 22.7 7.60 7.60 7.60 31.6 31.6 31.6
Input Specications, ELECTRIC Grills, Export, Non-CE Models MWE3W, MWE3S:
ELECTRICAL INPUT
SUPPLY
REQUIRED
TOTAL
kW
LOAD
LOADING: (kW/PHASE) NOMINAL AMPS PER LINE
200V / 60Hz 200V / 60Hz
L1/L2 L1/L3 L2/L3 L1 L2 L3
SINGLE INPUT 9.01 3.0 3.0 3.0 26.0 26.0 26.0
GAS INPUT SAME AS NORTH AMERICA (see next page)
Input Specications, GAS Grills, Japan:

Garland MWG3W Specifications

General

Brand	Garland
Model	MWG3W
Category	Grill
Language	English
