Garmin ECHOMAP UHD2 5 Series User Manual

7x Models
Dimensions, device only (W x H x D) 232 x 143.1 x 67 mm (9
1
/
8
x 5
5
/
8
x 2
5
/
8
in.)
Dimensions, in bail mount with sun cover (W x H x D) 243.4 x 153.9 x 105.5 mm (9
9
/
16
x 6
1
/
16
x 4
1
/
8
in.)
Display size (W x H)
86.9 x 155.1 mm (3
7
/
16
x 6
1
/
8
in.)
177.8 mm (7 in.) diagonal
Clearance to nearest obstruction behind chartplotter 62.5 mm (2
7
/
16
in.)
Weight 0.68 kg (1.5 lb.)
Max. power draw 15 W
Typical current draw at 12 Vdc (RMS) 1.1 A
Max. current draw at 12 Vdc (RMS) 1.25 A
Wireless frequency 2.4 GHz @ 19.7 dBm maximum
Compass-safe distance 12.7 cm (5 in.)
Appendix 69

Garmin ECHOMAP UHD2 5 Series Specifications

General

Brand	Garmin
Model	ECHOMAP UHD2 5 Series
Category	GPS
Language	English
