190-00709-00 Rev. A
Garmin G1000 Pilot’s Guide for the Socata TBM 850
5-73
FLIGHT MANAGEMENT
APPROACH (APPR)
An Approach Procedure (APPR) can be loaded at any airport that has an approach available. Only one
approach can be loaded at a time in a flight plan. The route for a selected approach is defined by designating
transition waypoints.
Figure 5-69 Approach Loading Page - Selecting the Approach
Destination Airport
Selected
Approach
Approaches Available at
KCOS
Approach Waypoint
Sequence
Preview of
Selected
Approach
Loading an approach procedure into a stored flight plan:
1) Select a stored flight plan from the Flight Plan Catalog Page.
2) Select the EDIT Softkey; or press the MENU Key, select ‘EDIT FLIGHT PLAN’, and press the ENT Key. The Stored
Flight Plan Page is displayed.
3) Select the LD APR Softkey; or press the MENU Key, select “Load Approach”, and press the ENT Key. The
Approach Loading Page is displayed.
4) Select an approach. Press the ENT Key.
5) Select a transition for the selected arrival. Press the ENT Key.
6) Press the ENT Key to load the selected approval procedure.
