Garmin GIA 6300 User Manual

190-01561-00
GIA 6300 Installation Manual
Draft1
Page 4
5 GIA6300 Interfaces
5.1 I/O Data Concentration and Computation (provided by Main Boards)
Table XXX lists the interfaces provided by Main A and Main B in the GIA 6300. Main A and Main B in the
GIA6300 function as two independent units, and interfaces to specific units should not be split across
the boards if practical. Additionally, where practical, primary and secondary sensors should be split
between the two boards so that one board does not directly connect to both the primary and secondary
sensor for given data.
Interface Description
Quantity
Comment
Active Low Discrete
Input
4
Active Low/High Discrete
Input
30
Active Low/High Discrete
Output
20
ARINC-429 Receiver
26
ARINC-429 Transmitter
8
ARINC-717/429
Transmitter
2
ARINC-717/708 Receiver
2
ARINC-743 GPS Time-
Mark Output
1
Ethernet
4
RS-485
14
RS-232
10
CAN
2
Analog Audio Output
1
5.1.1 Active Low/High Discrete Inputs and Outputs
The GIA 6300 has configurable discrete I/O in order to use the pins on the external connector more
efficiently. Each discrete interface, input and output, is configurable between either active high or low.

Garmin GIA 6300 Specifications

General

Display Size	10.4" diagonal
Weight	15.9 lbs (7.2 kg)
Display Type	LCD
Touchscreen	No
Display Resolution	1024 x 768 pixels (XGA)
Resolution	1024 x 768 pixels (XGA)
Certifications	TSO-C113
Power Requirements	18-33 VDC
