101
Appendix C
Physical Specifi cations
Size: 6.18”W x 3.4”H x 2.22”D (15.7 x 8.64 x 5.72cm)
Weight: 1.5 lbs (.68 kg) with batteries
Display: 3.8" diagonal (9.65cm) high-contrast, FSTN display with backlighting (320
x 240 pixels, 12-gray levels)
Case: Fully gasketed, high-impact plastic alloy, waterproof to IEC 529-IPX-7
Temp. Range: 5°F to 158°F (-15°C to 70°C)
Performance
Receiver: WAAS- and Differential-capable 12 parallel channel receiver
Acquisition Times: Approx. 15 seconds (warm start)
Approx. 45 seconds (cold start)
Approx. 2 minutes (First Time/AutoLocate™)
Update Rate: 1/second, continuous
GPS Accuracy: *< 15 meters (49 feet) RMS 95% typical
DGPS (USCG) Accuracy: 3-5 meters (10-16 ft), 95% typical
DGPS (WAAS) Accuracy: 3 meters (10ft) 95% typical with DGPS corrections
Velocity Accuracy: 0.05 meter/sec steady state
Dynamics: 6g's
* Subject to accuracy degradation to 100m 2DRMS under the U.S. DOD-imposed Selective Availability Program.
Power
Batteries: 4 AA Alkaline (not included)
Battery Life: Up to 16 hours in Battery Saver Mode
External Power Source: 8-35 Vdc
Fuse: AGC/3AG - 2.0 Amp
Specifi cations
User Waypoints: 1000, with 10-character name
Routes: 50, reversible and with up to
50 points per route
Tracks: Up to 2500 points in active log
Up to 500 points per saved log,
with up to 15 saved logs
Base Map: Built in; available in Americas,
Atlantic (Europe) and Pacifi c
versions
Jeppesen Data: Available in Americas, Atlantic
(Europe) and Pacifi c coverage
areas.
Optional Data Card: Available in 8, 16, 32, 64 and
128 MB sizes
Optional Map Data: MapSource, available in City
Select, MapSource, Roads &
Recreation, Topo and Fishing
HotSpots versions
190-00283-00Backup.indd 101 12/8/2002, 8:09:54 PM
