25
• State of charge indication: 5-LED display of the state of charge;
when the lowest LED flickers, it means it’s time to charge the
battery.
Power Assistance (PA) level indication: display current PA level 0
to 4; if no LED displayed, level is 0; 1 to 4 is in accordance with the
PA level. In Power Assistance mode, the LEDs will light up one by
one from down to up with a 0.5 second time interval (as shown in
the figure above).
LED indication definition
(from down to up)
State of charge
5 > 75%
4 50% - 75%
3 30% - 50%
2 10% - 30%
1 < 10%
1 flicker ≤ 5%
6.2 DISPLAY
Bluetooth
Light sensor
PA level
State of change
