If you are not familiar with the Mag-
nascanner, it is recommended that you
view the Video that accompanied this
unit before beginning this checklist. To
prepare the Magnascanner for use...
YOU MUST:
❏ 1. Assemble unit and move to desired
location. Make necessary arrangements
of surrounding furniture and equipment.
(See Site Selection, Page 7.) Attach
cables necessary for remote consoles,
multiunit slaving, or control relays.
❏ 2. Connect unit to power source and
observe LCD panel. The unit will begin
the self test sequence automatically
when power is connected. Correct any
problems reported. (See Self-Diagnostic
Tests, Page10.)
❏ 3. Determine optimum program based
on your particular application. (See Pro-
grams, Page 35.)
❏ 4. Set unit to desired program (See
Supervisor Adjustments, Program, Page
14.)
❏ 5. Determine sensitivity setting
required, using the alarm level reading
and sample test objects selected for
your application. Be thorough; perform
the test at various elevations and orien-
tations for objects that produce the high-
est alarm level readings. (See Supervi-
sor Adjustments, Alarm Level Reading,
Page 15.)
❏ 6. Set sensitivity to value determined
in step 6.2 (See Supervisor Adjustments,
Sensitivity, Page14.)
❏ 7. Return to Operate Mode by pressing
OPERATE touchpad.
❏ 8. Perform verifications test using
selected objects. (See Supervisor
Responsibilities, Page 16.)
STANDARD SETUP AND
OPERATION PROCEDURE
YOU MAY ALSO:
❏ 9. If multiple unit operation is being uti-
lized, verify units are properly inter-
leaved. (See Multiple Unit Operation,
Page 38.)
❏ 10. If unit appears noisy, i.e. more than
two LED s persistently displayed on bar
graph, further adjustments are required,
proceed to Step 11. If unit appears
quiet, proceed to Step 13.
❏ 11. Adjust video filter until noise sub-
sides. (See Installation Adjustments,
Video Filter, Page 13.)
❏ 12. Repeat steps 4-8.
❏ 13. Adjust tone to desired level. (See
Installation Adjustments, Tone, Page 12.)
❏ 14. Adjust volume to desired level. (see
Operating Instructions, Volume, Page 5.)
❏ 15. Alter access codes, if desired. (See
Installation Adjustments. Alter Access
Code #1 and #2, Page 13.)
SECURITY
When used in a security (weapons detection)
application, it is important that the following
procedures be followed:
1. Determine the security level appropriate to the
application.
2. Select test object(s) that will allow calibration
and verification of the desired settings.
3. Maintain the Operation Work Sheet shown on
Page 34 of this booklet.
4. Using the same test objects, verify the calibra-
tion daily and any time the equipment is moved
or the operating environment changes.
5. Seek corrective action immediately for any
problems or performance deficiencies and report
problems/deficiencies to the sales representative
and manufacturer as well.
Magnascanner, Super Scanner and Enforcer G-2 are “ of Garrett Electronics, Inc.
If further assistance is required, call the factory at 1-800-234-6151.
