EC / MC / SM 2005 -
72
-
7- Brake disc
8- Front suspension
9- Brake fluid reservoir
10- Fuel tank
11- Carburetor
12- Rear shock absorber
13- Brake caliper
14- Radiator
15- Gasoline cock
16- Shift pedal
17- Air cleaner
18- Muffler
19- Seat
20- Gas reservoir
21- Chain guide
22- Chain
23- Suspension linkage and swingarm
24- Rear brake pedal
25- Kick-start pedal
26- Exhaust
8
14
10
17
197
13 9
21
12 18
24 25
9
22
2011
1615
2623
GAS GAS EC 2005
