EC / MC / SM 2005 -
70
-
Primary reduction 2.85 (57/20)
Final reduction 3.615 (47/13)
Overall gear ratio 8.149 (6th gear)
Transmission oil Capacity 750 cc. ( 125 c.c. )
900 cc. ( 200 c.c. / 250 c.c. / 300 c.c. )
Type 10W30 API SF or SG.
CHASSIS
Type Tubular, semi-double cradle.
Tire size Front EC & MC - 90/90 x 21.
SM - 120/60 ZR17.
Rear EC - 140/80 x 18.
MC - 120/80 x 19.
SM - 150/60 ZR17.
Suspension Front Inverted telescopic fork Marzocchi ø 45 mm (only EC and SM )
Inverted telescopic fork Marzocchi ø 50 mm (only MC )
Inverted telescopic fork ÖHLINS.
Rear Progressive system with single multi-adjustable shock ÖHLINS.
Suspension stroke Front 282 mm.
Rear 320 mm.
Front fork oil Marzocchi SAE 7,5.
ÖHLINS SAE 5 - 7,5.
Front fork oil level Marzocchi: 110 mm (compressed, without spring)
ÖHLINS: 110 mm (compressed, without spring)
BRAKES
Type Front, Rear Disc brake
Effective disc diameter Front 260 mm. (only EC and MC )
320 mm. (only SM )
Rear 220 mm.
DIMENSIONES
Overall height 1260 mm.
Overall length 2135 mm.
Overall width 810 mm.
Seat height 940 mm.
Minimum height 340 mm.
Wheelbase 1475 mm.
Fuel tank capacity 9 l.
(Specifications are subject to change without notice and probably do not apply to all countries).
