The standard PC 707 crimper
(P/N 7480-0043/77700) requires a 115V,
15A power source. It is possible to operate
the crimper with a 230V, 15A power source.
However, a 230V wiring harness must be
purchased and the pump must be rewired to
use the PC 707 as a 230V machine. If the
crimper is not rewired when operated at 230V,
the LED digital readout will be damaged. Other
problems may also occur if the PC 707 is not
operated using the proper power source.
INSTRUCTIONS
Purchase a new, 230V wiring harness (Prod.
No.: 7482-0498 / Part No.: 78748).
Unplug the pump from the power source.
Remove the shroud from the PC 707 by
removing the two allen screws on the front of
the shroud.
Replace the old wiring harness between the
digital readout meter and the switchbox with
the new, 230V wiring harness.
Place the shroud on the crimper.
Unplug the pump from the crimper switchbox.
Rewire the pump for 230V. Note: For added
convenience, Gates offers a 230V Conversion
kit (7482-0499; part no 78760) including:
1. 220VAC cord assembly 7482-0496
2. 220VAC wall plug
3. Installation instructions
REWIRING THE PUMP
A. Unplug the pump from the wall outlet.
B. Remove the coverplate on the end
of the motor control box and, per the
instructions on back of coverplate,
change the motor leads to the 230V
configuration.
C. Re-install the coverplate on the motor
control box.
D. Install a new, 230V, 15A male plug on
the power cord.
E. Check the plug types for the connectors
(one from the pump and one from the
crimper) between the pump and the
switch box. Both plugs should be rated
for at least 230V and 15A to be used
with a 230V PC 707. If these plugs
are not rated to handle 230V and 15A,
then replace both plugs with nema
L6-15 plugs.
After all the re-wiring is completed and the
plug and wire types checked (and changed, if
necessary), re-connect the pump to the pump
source and the crimper.
MEASURING CRIMP DIAMETER
PC 707 CRIMPER SAFETY AND OPERATING MANUAL
