Gates PC 707 - Specifications

2
Die sets are available for crimping hydraulic and industrial hose from
3
⁄16
” through 1
1
⁄4
” I.D.. A Swager Kit
(Prod. No. 7480-0040, Part No. 78081) also is available to swage thermoplastic and C14 PTFE hoses.
PC 707 8-FINGER DIE SETS AVAILABLE
Product Part
Description Number Number Notes
Die Set 721 7482-1217 78943
Die Set 722 7482-1218 78944
Die Set 731 7482-0931 78931
Die Set 732 7482-0932 78932
Die Set 733 7482-0933 78933
Die Set 734 7482-0934 78934
Die Set 735 7482-0935 78935
Die Set 736 7482-0936 78936
Die Set 737 7482-0937 78937
Die Set 739 7482-0939 78939 Must use the No-Notch Die Cone (Prod. No. 7482-0297, Part No. 78747)
Die Set 740 7482-0947 78950 For crimping 6ACA
Die Set 741 7482-0941 74951 For crimping 8ACA
Die Set 742 7482-0942 78952 For crimping 10ACA
Die Set 743 7482-0943 78953 For crimping 12ACA
Die Set 744 7482-0944 78954 For crimping power steering
Die Set 745 7482-0945 78955 For crimping grease fitting
Die Set 746 7482-0946 78956 For crimping miscellaneous (Replaces B die)
Die Set 781 7482-1231 78578 For GL Fittings
Die Set 782 7482-1232 78579 For GL Fittings
Die Set 783 7482-1233 78580 For GL Fittings
Die Set 7C3 7482-1122 78941 For crimping clamp collar (
5
⁄8”)
Die Set 7C4 7482-1123 78942 For crimping clamp collar (
3
⁄4”)
Die Set 73234 (LG) 7482-1424 78763
Die Set 73335 (LG) 7482-1425 78764
Die Set 73436 (LG) 7482-1426 78765
Die Set 73537 (LG) 7482-1427 78766
Die Set 73638 (LG) 7482-1428 78767
Die Set 771 (GLP) 7482-1347 78957
Die Set 773 (GLP) 7482-1359 78959
Die Set 774 (GLP) 7482-1360 78960
Die Set 775 (GLP) 7482-1361 78961
Prod. No.: 7480-0043* Part No.: 77700*
Dimensions: 13” wide x 12” deep x 26-1/2” high
Weight: 188 lbs.
Production Rate: 50 assemblies per hour (1/2” I.D.
2-wire straight thread assemblies)
* Power Crimp 707 crimper can also be wired for 230 volts. To do this order PC
707 230V converter kit (Prod. No. 7482-0499, Part No 78760).
Power Crimp
®
707 Crimper
Prod. No.: 7481-0023 Part No.: 77810
Power Source: 115 Volt, 15 Amp.,1 H.P., 60
Cycles
Dimensions: 12 “ wide x 25” deep x 12” high
Weight: 70 lbs.
Maximum Rated Working Pressure: 4900 psi.
Electro Power Pump
Do not use 720, 737, or 739 die set with notched die cone (sold separately). May cause damage to die cone.
CAUTION:
SPECIFICATIONS
PC 707 CRIMPER SAFETY AND OPERATING MANUAL
Do not use 720, 737, or 739 die set with notched die cone (sold separately). May cause damage to die cone.
