3
Left side
www.gateway.com
Left side
Component Icon Description
Modem jack Plug a modem cable into this jack. For more information, see
“Connecting the modem” on page 34.
Ethernet jack Plug a 10/100 Ethernet network cable into this jack. For more
information, see “Connecting to a wired Ethernet network” on
page 35 and “Networking Your Computer” on page 155.
USB ports Plug USB (Universal Serial Bus) devices (such as a USB
Iomega™ Zip™ drive, printer, scanner, camera, keyboard, or
mouse) into these ports.
IEEE 1394 port Plug an IEEE 1394 (also known as Firewire
®
or i.Link
®
) device
(such as a digital camcorder) into this 4-pin IEEE 1394 port.
PC Card slot Insert one Type II or one Type III PC Card into this slot. For more
information, see “Adding and removing a PC Card” on page 208.
PC Card
eject
button
PC Card
slot
Microphone jack
Headphone jack
IEEE 1394 port
USB ports
Modem jack
Ethernet jack
Diskette drive
