Inside the computer 7
Inside the computer
The following illustration shows locations of various system components:
A System board
B Riser card
C Power supply release lever
D Power supply
E Hard drive (hard drive shown here in top bay: bay location may
vary)
F Diskette drive
G CD drive
A
BB
C
D
E
F
G
