10 System Features
Riser card
The riser card is mounted to the chassis by three screws at the top. The riser
card includes a chassis intrusion switch to alert you if the computer cover is
removed. It also includes five PCI connectors for add-on cards.
Front
A Secondary IDE connector
B CD/diskette drive power connector
C Wake-on LAN connector (WOL)
D Net Alert connector
E Ring-in connector
F System board connectors
G System chassis fan connector
B C DE
G
HIJ
K
L
M
N
O
P
Q
AF
