Instructions for SW200DC
www.gatexpertstore.com
11
前 安 装 板
安 装 螺 钉 （ 短 ）
M8自 锁 螺 母
Figure 9
8.3 Dimension of Control Box
250mm
170mm
78.75mm
Figure 10
Front mounting
bracket
Self-locking nut
Mouting screw(short)
