GATEXPERT SW200DC - Control Board Configuration

Instructions for SW200DC
www.gatexpertstore.com
18
Figure 16
9.6.3 Special Remote Control Key-button
Press and hold the combination keys for 5S.
C(stop)+D(single gate) combination key -- enter into remote control learning.
9.7 Control Board Settings
9.7.1 Base Menu
Press "PROG" to enter into base menu;
Digital screen shows “NE”, select other functions of this menu by “+” and “-” buttons.
Press "SET" to confirm or to enter into sub-menu.
To exit menu, press "PROG".
If no command for one minute, the menu will automatically exit.
Base Menu
External three keys
Automatic closing mode
Standard mode
Open/Close/Stop
Community mode
To select
working
mode
Initial
External three keys
(Automatic closing with)
