7.0 ELECTRICAL INTERFACE SPECIFICATION
7.1 Power
7.1.1 Power Supply
Voltage: 12VDC +/- 10% Regulated
3
Signal Input High Voltage: 5.5VDC
Signal Minimum Voltage: 0V
7.1.2 Power Consumption
Quiescent: 200mA
Validating: 800mA
Stalled: 1.4A
Maximum Output Low Voltage: 0.4VDC
Minimum Output High Voltage: 2.4VDC
Maximum output sink current: 50mA @ 12VDC
(Open collector)
Input pull up to 5V: 21K ohm
7.2 Outputs
Open Collector outputs;
Maximum Open Voltage 40V
Maximum Sink Current 50mA
I/O Drivers
Signal interfaces are buffered by use of Toshiba TD6283 or equivalent.
The outputs are open collector.
Inputs:
High > 3.5 V
Low < 0.3 V
3
For Power packs, 12vDC connection should be Tip Negative.
