GBA ST2 - Connection Requirements and Environmental; ccTalk;MDB Connections and Environmental Range

GBA Global Bill Acceptors GBA ST2
Operations Manual
Page 16 of 25
Astrosys International Ltd
January 2009
GBA ST2 Op Manual V1.01
0V
Vcc
o/p
i/p
14K
7K
1K
20K
6283 Schematic
ccTalk
®
Connection
If the validator is used in a ccTalk
®
interface application, an additional harness is required.
Part Number: HCC
Please contact Technical Support for details.
MDB Connection
If the validator is used in an MDB interface application, an additional power supply or conversion
board is required.
Part Number: TBA
Please contact Technical Support for details.
For further details relating to the operation of specific interfaces, please refer to the Interface
Description Manual.
7.3 Environmental
Humidity min 5%
max 95% (non condensing)
Temperature min 0
o
C
max +60
o
C
