Expert Pro User Manual
General Information
1-4
1.4.2 The Back View (Figure 1-2)
1.4.3 The Whole View (Figure 1-3)
** The Expert Pro model comes with a standard stand
Pinch Rollers
hold the media during cutting.
Lever
raises or lowers
the pinch rollers.
Figure 1-2
Figure 1-3
Roll Holder
h
olds and supplies the
roll media for cutting.
Stand Beam
stabilizes the body.
Roll Holder
Support
supports roll holders
T-Stand – supports
the cutting plotter
T-Stand – supports
the cutting plotter
