GDS VCI - Main Components; Information Terminal Specifications; Component Identification

User’s Manual
10
Figure 1. Component Identification
Information Terminal Specifications
Refer To CF-18 Manual or your purchased lap top manual.
Main Components
Trigger Module Connector
Mini USB Connector
DLC Connector
VCI Status Display
Power Switch
Module: A-01-002 (p.03)
