User’s Manual
14
Installation of VCI Module
and DLC Main Cable
Hardware
Module: A–01-004 (p.01)
First, confirm the position of the Data link Connector (DLC).
The location of the Data Link Connector (DLC) may vary depending on the type of vehicle.
z It is usually installed in the lower instrument panel, on the driver’s side.
z The DLC may be installed in the engine room. Check for the proper location on each vehicle.
Figure 1. Connect the DLC main Cable to the OBD-II Connector
Installation of Main DLC Cable
