GDS VCI - Installation of VCI Module; Connecting DLC Main Cable to VCI Module

User’s Manual
16
The VCI should be secured in a safe location when operating the vehicle to avoid interference with
other vehicle equipment.
Be sure that the DLC main cable is connected securely.
Figure 2. Connecting DLC main Cable to VCI module
Installation of VCI Module
Module: A-01-004 (p.03)
