GDS VCI - System Specifications

User’s Manual
8
Specifications and Features
Hardware
Module: A–01-002 (p.01)
VCI Specifications
General Features
Item Specifications
Micro Controller ARM9 (S3C2410A) @ 208MHz
Memory RAM 32MByte
ROM 32MByte
Operating Voltage 7~35VDC
Temperature Operating
-10℃ ~ 70℃ (14℉ ~ 158℉): USB Mode
-10℃ ~ 55℃ (14℉ ~ 131℉): Wireless LAN Mode
Storage
-20℃ ~ 80℃ (-4℉ ~ 176℉)
Relative
Humidity
Operating
Noncondensing @ 0℃ ~ 10℃ (32℉ ~ 50℉)
95%RH @ 10℃ ~ 30℃ (50℉ ~ 86℉)
70%RH @ 30℃ ~ 50℃ (86℉ ~ 122℉)
40%RH @ 50℃ ~ 70℃ (122℉ ~ 158℉)
Storage
Noncondensing @ -20℃ ~ 80℃ (-4℉ ~ 176℉)
Operating Mode
Diagnosis Function / Flight Record Function
Current Consumption
Typical 350mA @12V
Housing
ABS & Rubber Shroud
Dimension
170 × 105 × 33 mm
Weigh
350g
PC Interface
Item Specifications
Wire protocol USB 1.1
Wireless protocol Wireless LAN IEEE 802.11b
