ESL 1500 Series Fire Alarm Control Panel
Specifications
General
Operating temperature........................ 0° to 49°C (32° to 120°F)
Housing
Type............................Steel with hinged/removable, locking door
Size..........14.0 in. x 14.0 in. x 4.5 in.(35.6cm x 35.6cm x 11.4cm)
Finish..................................................Red, sand textured, enamel
Weight.................................................... 15 lbs. max. w/o battery
1500-BMB- Basic Master Board
Power
Input power............................................120 VAC, 60Hz, 56 V A
Standby power................................................................ 24 VDC
Auxiliary power output...................... 24 VDC FWR, 1.0 A max.
............................................................(32.1 VDC max. - no load)
Note: Auxiliary power output supply is shared with power
for indicating circuit. Consider total requirements.
(I aux + I IND#1 + I IND#2 = 1.5 A)
Optional standby battery.................................................. 24 Volt
Battery charger rate.................................................. 700 mA max.
Battery charge voltage................................................... 29 V max.
Alarm initiating circuits
Number of circuits............................................ One - model 1501
Three - model 1503
Five - model 1505
Type................................... Class A or B, Latched (Style B or D)
End-of-line................................................. 2.7 K Ohms, 1/2 Watt
Loop powered device current........................................... 2.0 mA
Alarm current..................................................................... 15 mA
Maximum current............................................................... 60 mA
Maximum voltage............................................................. 17 Volts
Normal circuit voltage................................................... 14.7 Volts
Minimum voltage.......................................................... 13.5 Volts
Maximum ripple voltage................................. 500 Millivolts AC
Maximum line resistance.....100 Ohms(Compatibility Ident.C01)
Ohms(Compatibility, Ident.C01A)
Alarm indicating circuits
Number of circuits ................... Two Class A or B (Style Y or Z)
Maximum current per circuit......................................... 1.0 Amps
Maximum total current ................................................. 1.5 Amps
Output voltage ..................................................... 24 VDC, FWR
End-of-line ................................................ 2.7 K Ohms, 1/2 Watt
Supplementary alarm/trouble contacts
System trouble ................................... 2.0 A @ 30 VDC resistive
System alarm ...................................... 2.0 A @ 30 VDC resistive
Sounder output
Alarm...................................................................Constant output
Fault ..................................................... -0.25 sec. on; 2.5 sec. off
Supervisory ....................................... -0.25 sec. on; 0.25 sec. off
Remote indicator
Voltage ........................................................................ 12 VDC
Current ................................................................. 15 mA max.
1500-ZEM - Zone Expander Module
Initiating circuits
Number of circuits ........................................................... Two
Type .............................. Class A or B, latched (Style B or D)
End-of-line............................................ 2.7 K Ohms, 1/2 Watt
Loop powered device current...................................... 2.0 mA
Alarm current ............................................................... 15 mA
Maximum current ......................................................... 60 mA
Maximum voltage ....................................................... 17 Volts
Normal circuit voltage ............................................. 14.7 Volts
Minimum voltage .................................................... 13.5 Volts
Maximum ripple voltage ............................ 500 Millivolts AC
Maximum line resistance
100 Ohms(Compatibility Ident. C01)
50 Ohms (Compatibility Ident. C01A)
Remote Indicator
Voltage ........................................................................ 12 VDC
Current ................................................................. 15 mA max.
1500-LEM - Local Energy Module
Output characteristics
Standby ........................................................ 2 VDC (no load)
Alarm ............................................................... 24 VDC FWR
Trouble ........................................................................ 0 VDC
Alarm current ..................................................... 320 mA max.
Standby current .............................................................. 1 mA
1500-ZRM-5 - Zone Relay Module
Output characteristics
Voltage ........................................................................ 12 VDC
Standby current ............................................. 0 mA per circuit
Alarm current .............................................. 15 mA per circuit
Contact ratings .......................................... 3 A @ 30 VAC/DC
1500-RA-5A - Remote Annunciator
Output Characteristics
Number of zones ......................................... 5 alarm, 1 trouble
Voltage ........................................................................ 12 VDC
Standby current ............................................. 0 mA per circuit
Trouble current ............................................................ 50 mA
Alarm current .............................................. 15 mA per circuit
