GE Security 1501 User Manual

2 ESL 1500 Series Fire Alarm Control Panel
Panel Description
Standard Features:
• Modular design; 1, 3, or 5 zones
• Power limited
• 1.5 Amp. 24 VDC FWR output
• All functions DIP switch activated
• Built-in walktest and alarm verification
• Sprinkler supervisory and waterflow alarm activation
• Class A (Style D) or Class B (Style B) initiating wiring
• Reliability of surface-mount design
• Superior lightning protection
Table 1. Ordering Information
Model Title Description
1501 Single zone fire panel 1 initiating circuit,
2 indicating circuits
1503 Three zone fire panel 3 initiating circuits,
2 indicating circuits
1505 Five zone fire panel 5 initiating circuits,
2 indicating circuits
1500-BMB Basic Master Board 1 initiating circuit,
2 indicating circuits
1500-ZEM Zone Expansion Module 2 initiating circuits,
Class A or B
1500-LEM Local Energy Module Connect to Listed
master box
1500-ZRM-5 1500 Zone Relay Module 5 relays
1500-SH System housing System housing
with transformer
1500-TK Flush mount trim ring Mounting panel
semi-flush with wall
1500-TR Transformer Transformer
replacement
1500-2.7 End-of-line resistor Initiating and
indicating circuits
2.7 Ky 1/2 W
1500-RA-5A Remote Annunciator 5 alarm zones w/
trouble and
sounder
204-12/24 V Power supervision unit EOL power
supervisory unit
405-01 Polarity reversal relay Single circuit,
24 VDC
Optional Features:
• Local Energy Module (LEM)
• Zone Relay Module (ZRM) 5 relays
• Remote Annunciators (RA)

GE Security 1501 Specifications

General

Brand	GE Security
Model	1501
Category	Control Panel
Language	English
