Conf
iguring the read
er
27
Selecting be
eper sound level
The ta
ble be
low shows
the DIP s
witch s
etti
ngs for
the thr
ee
beepe
r sound
level
s.
Table 5.
Beep
er sou
nd l
evel DIP
swit
ch s
etting
s
Beeper s
ound
level
Switch 7
Switch 8
Normal
ON
ON
Low
ON
OFF
Off
OFF
ON
30
32
Table of Contents
Default Chapter
1
Installation Manual
1
Table of Contents
3
Introduction
5
Safety
6
Radio Interference
6
Electrostatic Discharge (ESD) Precaution
6
Product Features
7
System Requirements
8
Technical Specifications
9
Parts List
10
Installation Overview
11
Mounting the Reader
12
Back-To-Back Readers
13
External Tamper Feature
13
Figure 1. Recommended Additional Mounting Instructions for External Tamper Switch Activation
13
Figure 2. Model 940 Reader - Gang Box Mounting
13
Mounting Diagrams
14
Figure 3. Model 940 Reader - Direct Wall Mounting
14
Figure 4. Model 941 Reader - Gang Box Mounting
14
Figure 5. Model 941 Reader - Direct Wall Mounting
14
Figure 6. Model 970/972 Reader - Gang Box Mounting
20
Figure 7. Model 970/972 Reader - Direct Wall Mounting
21
Figure 8. Model 971/973 Reader - Gang Box Mounting
22
Figure 9. Model 971/973 Reader - Direct Wall Mounting
23
Configuring the Reader
24
Switch Settings
24
Selecting Reader Power Level
24
Figure 10. Model 94X/97X Reader, J1 Connector and DIP Switch Locations (PCB Assembly P/N 100079002 Manufactured 12/02 or Later)
26
Figure 11. (PCB Assembly P/N 100079001 Manufactured Prior to 12/02)
27
Selecting Operating Mode
30
Selecting Beeper Sound Level
31
Connecting the Reader
32
Pinouts
32
Wiring Diagrams
33
Figure 12. Wiring Diagram, Model 94X/97X
33
Figure 13. Wiring Diagram, Model 94X/97X
33
Figure 14. Wiring Diagram, Model 94X/97X Unsupervised Wiegand Mode
33
Testing the Reader
40
Troubleshooting the Reader
42
All Installations
42
Unsupervised Modes Only
45
Supervised Modes Only
45
Regulatory Approvals
48
Declaration of Conformity
49
Using Shielded Cable/Drain Wire
50
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the GE Security 940 and is the answer not in the manual?
Ask a question
GE Security 940 Specifications
General
Brand
GE Security
Model
940
Category
Security System
Language
English
