20
To remove roof:
1. Remove the five screws
A
that secure the roof to
the unit.
2. Carefully lift and remove roof from unit.
To remove front panel:
1. Remove the two screws
B
that secure the panel to the
unit.
2. Lift and flex panel outward and off base. Use caution
not to damage the battery box
C
.
To secure front panel:
1. Place panel in unit.
2. Secure the panel with two screws.
C
B
A
A
A
To Next Page
