489 Generator Management Relay 5-7
5 ACTUAL VALUES 5.2 A1 STATUS
5
LOSS OF EXCITATION 2
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
DISTANCE ZONE 1
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
DISTANCE ZONE 2
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
REACTIVE POWER
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
REVERSE POWER
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
LOW FORWARD POWER
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
RTD #1
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
RTD #2
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
RTD #3
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
RTD #4
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
RTD #5
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
RTD #6
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
RTD #7
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
RTD #8
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
RTD #9
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
RTD #10
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
RTD #11
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
RTD #12
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
THERMAL MODEL
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip.
ANALOG I/P 1
PICKUP: Not Enabled
Range: Not Enabled, Inactive, Timing Out, Active Trip,
Latched Trip. Reflects programmed Analog Input
Name. Seen only if input is enabled.
ANALOG I/P 2
PICKUP: Not Enabled
Range: see ANALOG I/P 1 above
ANALOG I/P 3
PICKUP: Not Enabled
Range: see ANALOG I/P 1 above
