GE 489 User Manual

GE Power Management
489 Generator Management Relay 5-11
5 ACTUAL VALUES 5.2 A1 STATUS
5
5.2.6 DIGITAL INPUTS
The messages shown here may be used to monitor digital input status. This may be useful during relay testing or during
installation.
5.2.7 REAL TIME CLOCK
The time and date from the 489 real time clock may be viewed here.

DIGITAL INPUTS

[ENTER] for more
ACCESS
SWITCH STATE: Open
Range: Open, Shorted
BREAKER STATUS
SWITCH STATE: Open
Range: Open, Shorted
ASSIGNABLE DIGITAL
INPUT1 STATE: Open
Range: Open, Shorted
ASSIGNABLE DIGITAL
INPUT2 STATE: Open
Range: Open, Shorted
ASSIGNABLE DIGITAL
INPUT3 STATE: Open
Range: Open, Shorted
ASSIGNABLE DIGITAL
INPUT4 STATE: Open
Range: Open, Shorted
ASSIGNABLE DIGITAL
INPUT5 STATE: Open
Range: Open, Shorted
ASSIGNABLE DIGITAL
INPUT6 STATE: Open
Range: Open, Shorted
ASSIGNABLE DIGITAL
INPUT7 STATE: Open
Range: Open, Shorted
TRIP COIL
SUPERVISION: No Coil
Range: Open, Shorted

REAL TIME CLOCK

[ENTER] for more
DATE: 01/01/1995
TIME: 12:00:00
Range: 01/01/1995 to 12/31/2094, 00:00:00 to 23:59:59
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
ENTER
ESCAPE
ð
ð
