6.3 MEMORY MAP 6 COMMUNICATIONS
6
0320 RTD #12 PICKUP 0 to 4 1 – F123 0
0321 OPEN SENSOR PICKUP 0 to 4 1 – F123 0
0322 SHORT/LOW TEMP PICKUP 0 to 4 1 – F123 0
0323 THERMAL MODEL PICKUP 0 to 4 1 – F123 0
0324 TRIP COUNTER PICKUP 0 to 4 1 – F123 0
0325 BREAKER FAILURE PICKUP 0 to 4 1 – F123 0
0326 TRIP COIL MONITOR PICKUP 0 to 4 1 – F123 0
0327 VT FUSE FAILURE PICKUP 0 to 4 1 – F123 0
0328 CURRENT DEMAND PICKUP 0 to 4 1 – F123 0
0329 MW DEMAND PICKUP 0 to 4 1 – F123 0
032A Mvar DEMAND PICKUP 0 to 4 1 – F123 0
032B MVA DEMAND PICKUP 0 to 4 1 – F123 0
032C ANALOG INPUT 1 PICKUP 0 to 4 1 – F123 0
032D ANALOG INPUT 2 PICKUP 0 to 4 1 – F123 0
032E ANALOG INPUT 3 PICKUP 0 to 4 1 – F123 0
032F ANALOG INPUT 4 PICKUP 0 to 4 1 – F123 0
0330 NOT PROGRAMMED PICKUP 0 to 4 1 – F123 0
0331 SIMULATION MODE PICKUP 0 to 4 1 – F123 0
0332 OUTPUT RELAYS FORCED PICKUP 0 to 4 1 – F123 0
0333 ANALOG OUTPUT FORCED PICKUP 0 to 4 1 – F123 0
0334 TEST SWITCH SHORTED PICKUP 0 to 4 1 – F123 0
0335 GROUND DIRECTIONAL PICKUP 0 to 4 1 – F123 0
0336 IRIG-B ALARM PICKUP 0 to 4 1 – F123 0
0337 GENERATOR RUNNING HOUR PICKUP 0 to 4 1 – F123 0
STATUS / DIGITAL INPUTS
0380 ACCESS SWITCH STATE 0 to 1 1 – F207 0
0381 BREAKER STATUS SWITCH STATE 0 to 1 1 – F207 0
0382 ASSIGNABLE DIGITAL INPUT1 STATE 0 to 1 1 – F207 0
0383 ASSIGNABLE DIGITAL INPUT2 STATE 0 to 1 1 – F207 0
0384 ASSIGNABLE DIGITAL INPUT3 STATE 0 to 1 1 – F207 0
0385 ASSIGNABLE DIGITAL INPUT4 STATE 0 to 1 1 – F207 0
0386 ASSIGNABLE DIGITAL INPUT5 STATE 0 to 1 1 – F207 0
0387 ASSIGNABLE DIGITAL INPUT6 STATE 0 to 1 1 – F207 0
0388 ASSIGNABLE DIGITAL INPUT7 STATE 0 to 1 1 – F207 0
0389 TRIP COIL SUPERVISION 0 to 1 1 – F132 0
STATUS / REAL TIME CLOCK
03FC DATE (READ-ONLY) N/A N/A N/A F18 N/A
03FE TIME (READ-ONLY) N/A N/A N/A F19 N/A
METERING DATA / CURRENT METERING
0400 PHASE A OUTPUT CURRENT 0 to 999999 1 Amps F12 0
0402 PHASE B OUTPUT CURRENT 0 to 999999 1 Amps F12 0
0404 PHASE C OUTPUT CURRENT 0 to 999999 1 Amps F12 0
0406 PHASE A NEUTRAL-SIDE CURRENT 0 to 999999 1 Amps F12 0
0408 PHASE B NEUTRAL-SIDE CURRENT 0 to 999999 1 Amps F12 0
040A PHASE C NEUTRAL-SIDE CURRENT 0 to 999999 1 Amps F12 0
040C PHASE A DIFFERENTIAL CURRENT 0 to 999999 1 Amps F12 0
040E PHASE B DIFFERENTIAL CURRENT 0 to 999999 1 Amps F12 0
0410 PHASE C DIFFERENTIAL CURRENT 0 to 999999 1 Amps F12 0
0412 AVERAGE PHASE CURRENT 0 to 999999 1 Amps F12 0
0414 GENERATOR LOAD 0 to 2000 1 % FLA F1 0
0415 NEGATIVE SEQUENCE CURRENT 0 to 2000 1 % FLA F1 0
0416 GROUND CURRENT 0 to 10000 1 Amps F14 0
0420 PHASE A CURRENT ANGLE 0 to 359 1 ° F1 0
Table 6–1: 489 MEMORY MAP (Sheet 4 of 29)
ADDR NAME RANGE STEP UNITS FORMAT DEFAULT
1, 2, 3 See Table footnotes on page 6–39
