6-50 489 Generator Management Relay
GE Power Management
6.5 DNP POINT LISTS 6 COMMUNICATIONS
6
Any detected change in the state of any point
assigned to Class 1 will cause the generation of an
event object.
86 Ground Directional Trip Active or
Latched
Class 1
87 High Set Phase O/C Trip Active or
Latched
Class 1
88 Distance Zone 1 Trip Active or Latched Class 1
89 Distance Zone 2 Trip Active or Latched Class 1
90 … Reserved …
↓↓ ↓
99 … Reserved …
100 Assignable In 1 Alarm Active / Latched Class 1
101 Assignable In 2 Alarm Active or
Latched
Class 1
102 Assignable In 3 Alarm Active or
Latched
Class 1
103 Assignable In 4 Alarm Active or
Latched
Class 1
104 Assignable In 5 Alarm Active or
Latched
Class 1
105 Assignable In 6 Alarm Active or
Latched
Class 1
106 Assignable In 7 Alarm Active / Latched Class 1
107 Tachometer Alarm Active or Latched Class 1
108 Overcurrent Alarm Active or Latched Class 1
109 Neg Seq Alarm Active or Latched Class 1
110 Ground O/C Alarm Active or Latched Class 1
111 Undervoltage Alarm Active or Latched Class 1
112 Overvoltage Alarm Active or Latched Class 1
113 Volts/Hertz Alarm Active or Latched Class 1
114 Underfreq Alarm Active or Latched Class 1
115 Overfrequency Alarm Active or
Latched
Class 1
116 Neutral O/V (fundamental) Alarm
Active or Latched
Class 1
117 Neutral U/V (3
rd
harm) Alarm Active or
Latched
Class 1
118 Reactive Power Alarm Active or
Latched
Class 1
119 Reverse Power Alarm Active or
Latched
Class 1
120 Low Fwd Power Alarm Active /
Latched
Class 1
121 RTD #1 Alarm Active or Latched Class 1
122 RTD #2 Alarm Active or Latched Class 1
123 RTD #3 Alarm Active or Latched Class 1
124 RTD #4 Alarm Active or Latched Class 1
125 RTD #5 Alarm Active or Latched Class 1
126 RTD #6 Alarm Active or Latched Class 1
POINT LIST FOR: BINARY INPUT (OBJECT 01)
BINARY INPUT CHANGE (OBJECT 02)
(SHEET 3 OF 4)
INDEX DESCRIPTION EVENT
CLASS
ASSIGNED
127 RTD #7 Alarm Active or Latched Class 1
128 RTD #8 Alarm Active or Latched Class 1
129 RTD #9 Alarm Active or Latched Class 1
130 RTD #10 Alarm Active or Latched Class 1
131 RTD #11 Alarm Active or Latched Class 1
132 RTD #12 Alarm Active or Latched Class 1
133 Open Sensor Alarm Active or Latched Class 1
134 Short/Low Temp Alarm Active /
Latched
Class 1
135 Thermal Model Alarm Active or
Latched
Class 1
136 Trip Counter Alarm Active or Latched Class 1
137 Breaker Failure Alarm Active or
Latched
Class 1
138 Trip Coil Monitor Alarm Active /
Latched
Class 1
139 VTFF Alarm Active or Latched Class 1
140 Current Dmd Alarm Active or Latched Class 1
141 MW Demand Alarm Active or Latched Class 1
142 Mar Demand Alarm Active or Latched Class 1
143 MVA Alarm Active or Latched Class 1
144 Analog Input 1 Alarm Active or
Latched
Class 1
145 Analog Input 2 Alarm Active or
Latched
Class 1
146 Analog Input 3 Alarm Active or
Latched
Class 1
147 Analog Input 4 Alarm Active or
Latched
Class 1
148 Not Programmed Alarm Active /
Latched
Class 1
149 Simulation Mode Alarm Active or
Latched
Class 1
150 Output Relays Forced Alarm Active or
Latched
Class 1
151 Analog Output Forced Alarm Active or
Latched
Class 1
152 Test Switch Shorted Alarm Active or
Latched
Class 1
153 Gnd Directional Alarm Active or
Latched
Class 1
154 IRIG-B Failure Alarm Active or Latched Class 1
155 Generator Running Hour Alarm Active
or Latched
Class 1
POINT LIST FOR: BINARY INPUT (OBJECT 01)
BINARY INPUT CHANGE (OBJECT 02)
(SHEET 4 OF 4)
INDEX DESCRIPTION EVENT
CLASS
ASSIGNED
NOTE
