5.5.2 Main Menu
Structure
Keypad Set-Up
K-0# Keypad Basic Settings
K-01 Language
K-02 Motor Speed Unit
K-03 Regional Settings
K-04 Operating State at Power-up
K-05 Local Mode Unit
K-1# Keypad Set-Up Operations
K-10 Active Set-up
K-11 Edit Set-up
K-12 This Set-up Linked to
K-13 Readout: Linked Set-ups
K-14 Readout: Edit Set-ups / Channel
K-2# Keypad Display
K-20 Display Line 1.1 Small
K-21 Display Line 1.2 Small
K-22 Display Line 1.3 Small
K-23 Display Line 2 Large
K-24 Display Line 3 Large
K-25 Quick Start
K-3# Keypad Custom Readout
K-30 Unit for Custom Readout
K-31 Min Value of Custom Readout
K-32 Max Value of Custom Readout
K-37 Display Text 1
K-38 Display Text 2
K-39 Display Text 3
K-4# Keypad Buttons
K-40 [Hand] Button on Keypad
K-41 [Off] Button on Keypad
K-42 [Auto] Button on Keypad
K-43 [Reset] Button on Keypad
K-5# Copy/Save
K-50 Keypad Copy
K-51 Set-up Copy
K-6# Password Protection
K-60 Main Menu Password
K-61 Access to Main Menu w/o Password
K-65 Quick Menu Password
K-66 Access to Quick Menu w/o Password
K-67 Bus Password Access
K-7# Clock Settings
K-70 Date and Time
K-71 Date Format
K-72 Time Format
K-74 DST/Summertime
K-76 DST/Summertime Start
K-77 DST/Summertime End
K-79 Clock Fault
K-8# Days and Date/Time Readout
K-81 Working Days
K-82 Additional Working Days
K-83 Additional Non-Working Days
K-89 Date and Time Readout
Parameter Data Set
F-## Fundamental Parameters
F-0# Fundamental 0
F-01 Frequency Setting 1
F-02 Operation Method
F-03 Max Output Frequency 1
F-04 Base Frequency
F-05 Motor Rated Voltage
F-07 Accel Time 1
F-08 Decel Time 1
F-09 Torque Boost
F-1# Fundamental 1
F-10 Electronic Overload
F-11 Motor External Fan
F-12 Motor Thermistor Input
F-15 Motor Speed High Limit [Hz]
F-16 Motor Speed Low Limit [Hz]
F-17 Motor Speed High Limit [RPM]
F-18 Motor Speed Low Limit [RPM]
F-2# Fundamental 2
F-20 PM Start Mode
F-24 Holding Time
F-26 Motor Noise (Carrier Freq)
F-27 Motor Tone Random
F-3# Fundamental 3
F-37 Adv. Switching Pattern
F-38 Overmodulation
F-4# Fundamental 4
F-40 Torque Limiter (Driving)
F-41 Torque Limiter (Braking)
F-43 Current Limit
F-5# Extended References
F-52 Minimum Reference
F-53 Maximum Reference
F-54 Reference Function
F-6# References
F-64 Preset Relative Reference
F-9# Digital Pot.Meter
F-90 Step Size
F-91 Accel/Decel Time
F-92 Power Restore
F-93 Maximum Limit
F-94 Minimum Limit
F-95 Accel/Decel Ramp Delay
E-## Digital In/Out
E-0# Digital Inputs
E-00 Digital I/O Mode
E-01 Terminal 18 Digital Input
E-02 Terminal 19 Digital Input
E-03 Terminal 27 Digital Input
E-04 Terminal 29 Digital Input
E-05 Terminal 32 Digital Input
E-06 Terminal 33 Digital Input
E-1# Additional Accel Decel Ramps
E-10 Accel Time 2
E-11 Decel Time 2
E-2# Digital Outputs
E-20 Terminal 27 Digital Output
E-21 Terminal 29 Digital Output
E-24 Function Relay
E-26 On Delay, Relay
E-27 Off Delay, Relay
E-5# I/O Mode / Add On I/O
E-51 Terminal 27 Mode
E-52 Terminal 29 Mode
E-53 Terminal X30/2 Digital Input
E-54 Terminal X30/3 Digital Input
E-55 Terminal X30/4 Digital Input
E-56 Term X30/6 Digi Out (OPCGPIO)
E-57 Term X30/7 Digi Out (OPCGPIO)
E-6# Pulse Input
E-60 Term. 29 Low Frequency
E-61 Term. 29 High Frequency
E-62 Term. 29 Low Ref./Feedb. Value
E-63 Term. 29 High Ref./Feedb. Value
E-64 Pulse Filter Time Constant #29
E-65 Term. 33 Low Frequency
E-66 Term. 33 High Frequency
E-67 Term. 33 Low Ref./Feedb. Value
E-68 Term. 33 High Ref./Feedb. Value
E-69 Pulse Filter Time Constant #33
E-7# Pulse Output
E-70 Terminal 27 Pulse Output Variable
E-71 Pulse Output Max Freq #27
E-72 Terminal 29 Pulse Output Variable
E-74 Pulse Output Max Freq #29
E-75 Terminal X30/6 Pulse Output Variable
E-76 Pulse Output Max Freq #X30/6
E-9# Bus Controlled
E-90 Digital & Relay Bus Control
E-93 Pulse Out #27 Bus Control
E-94 Pulse Out #27 Timeout Preset
E-95 Pulse Out #29 Bus Control
E-96 Pulse Out #29 Timeout Preset
E-97 Pulse Out #X30/6 Bus Control
E-98 Pulse Out #X30/6 Timeout Preset
C-## Frequency Control Functions
C-0# Frequency Control Functions
C-01 Jump Frequency From [Hz]
C-02 Jump Speed From [RPM]
C-03 Jump Speed To [RPM]
C-04 Jump Frequency To [Hz]
C-05 Multi-step Frequency 1 - 8
C-2# Jog Setup
C-20 Jog Speed [Hz]
C-21 Jog Speed [RPM]
C-22 Jog Accel/Decel Time
C-23 Quick Stop Decel Time
C-3# Frequency Setting 2 and 3
C-30 Frequency Command 2
C-34 Frequency Command 3
C-4# Semi-Auto Jump Freq Set-up
C-40 Semi-Auto Jump Freq Set-up
P-## Motor Data
P-0# Motor Data
P-02 Motor Power [HP]
P-03 Motor Current
P-04 Auto Tune
P-06 Base Speed
P-07 Motor Power [kW]
P-08 Motor Rotation Check
P-09 Slip Compensation
P-10 Slip Compensation Time Constant
P-2# Motor Selection
P-20 Motor Construction
P-24 Damping Gain
P-25 Low Speed Filter Time Const.
P-26 High Speed Filter Time Const.
P-27 Voltage filter time const.
P-3# Adv. Motor Data
P-30 Stator Resistance (Rs)
P-31 Rotor Resistance (Rr)
P-35 Main Reactance (Xh)
P-36 Iron Loss Resistance (Rfe)
P-39 Motor Poles
P-46 Position Detection Gain
P-6# Locked Rotor
P-62 Locked Rotor Protection
P-63 Locked Rotor Detection Time [s]
H-## High Perf Parameters
H-0# High Perf Operations
H-03 Restore Factory Settings
H-04 Auto-Reset (Times)
H-05 Auto-Reset (Reset Interval)
H-06 Fan Operation
H-08 Reverse Lock
H-09 Start Mode
H-3# Stop Speed
H-36 Trip Speed Low [RPM]
H-37 Trip Speed Low [Hz]
H-4# Advanced Settings
H-40 Configuration Mode
H-43 Torque Characteristics
H-48 Clockwise Direction
H-5# Load Indep. Setting
H-50 Motor Magnetisation at Zero Speed
H-51 Min Speed Normal Magnetising [RPM]
H-52 Min Speed Normal Magnetising [Hz]
H-58 Flystart Test Pulses Current
H-59 Flystart Test Pulses Frequency
H-6# Load Depen. Setting
H-61 High Speed Load Compensation
H-64 Resonance Dampening
H-65 Resonance Dampening Time Constant
H-7# Adjustable Warnings
H-70 Warning Current Low
H-71 Warning Current High
H-72 Warning Speed Low
H-73 Warning Speed High
H-74 Warning Reference Low
H-75 Warning Reference High
H-76 Warning Feedback Low
H-77 Warning Feedback High
H-78 Missing Motor Phase Function
H-8# Stop Adjustments
H-80 Function at Stop
H-81 Min Speed for Function at Stop [RPM]
H-82 Min Speed for Function at Stop [Hz]
AN-## Analog In/Out
AN-0# Analog I/O Mode
AN-00 Live Zero Timeout Time
AN-01 Live Zero Timeout Function
AN-02 Fire Mode Live Zero Timeout Function
AN-1# Analog Input 53
AN-10 Terminal 53 Low Voltage
AN-11 Terminal 53 High Voltage
AN-12 Terminal 53 Low Current
AN-13 Terminal 53 High Current
AN-14 Terminal 53 Low Ref./Feedb. Value
AN-15 Terminal 53 High Ref./Feedb. Value
AN-16 Terminal 53 Filter Time Constant
AN-17 Terminal 53 Live Zero
AN-2# Analog Input 54
AN-20 Terminal 54 Low Voltage
AN-21 Terminal 54 High Voltage
AN-22 Terminal 54 Low Current
AN-23 Terminal 54 High Current
AN-24 Terminal 54 Low Ref./Feedb. Value
AN-25 Terminal 54 High Ref./Feedb. Value
AN-26 Terminal 54 Filter Time Constant
AN-27 Terminal 54 Live Zero
AN-3# Analog Input X30/11
AN-30 Terminal X30/11 Low Voltage
AN-31 Terminal X30/11 High Voltage
AN-34 Term. X30/11 Low Ref./Feedb. Value
AN-35 Term. X30/11 High Ref./Feedb. Value
AN-36 Term. X30/11 Filter Time Constant
AN-37 Term. X30/11 Live Zero
AN-4# Analog Input X30/12
AN-40 Terminal X30/12 Low Voltage
AN-41 Terminal X30/12 High Voltage
AN-44 Term. X30/12 Low Ref./Feedb. Value
AN-45 Term. X30/12 High Ref./Feedb. Value
AN-46 Term. X30/12 Filter Time Constant
AN-47 Term. X30/12 Live Zero
AN-5# Analog Output 42
AN-50 Terminal 42 Output
AN-51 Terminal 42 Output Min Scale
AN-52 Terminal 42 Output Max Scale
AN-53 Terminal 42 Output Bus Control
AN-54 Terminal 42 Output Timeout Preset
AN-55 Terminal 42 Output Filter
AN-6# Analog Output X30/8
AN-60 Terminal X30/8 Output
AN-61 Terminal X30/8 Min. Scale
AN-62 Terminal X30/8 Max. Scale
AN-63 Terminal X30/8 Output Bus Control
AN-64 Terminal X30/8 Output Timeout Preset
SP-## Special Functions
SP-0# Fault Settings
SP-00 Fault Level
SP-1# Line On/Off
SP-10 Line failure
SP-11 Line Voltage at Input Fault
SP-12 Function at Line Imbalance
SP-2# Reset Functions
SP-23 Typecode Setting
About Programming
AF-600 FP
TM
Design and Installation Guide
38 DET-768b
