7.1.3 EMC Test Results (Emission)
The following test results have been obtained using a system with a frequency converter (with options if relevant), a
screened control cable, a control box with potentiometer, as well as a motor and motor screened cable.
RFI filter type Conducted emission
Maximum shielded cable length
Radiated emission
Industrial environment Housing, trades
and light
industries
Industrial
environment
Housing, trades and light
industries
Standard EN 55011
Class A2
EN 55011
Class A1
EN 55011
Class B
EN 55011
Class A1
EN 55011
Class B
Class A1/B RFI Filter installed
0.75-45 kW 200-240 V 150 m 150 m 50 m Yes No
0.75-90 kW 380-480 V 150 m 150 m 50 m Yes No
Class A2 RFI Filter installed
0.75-3.7 kW 200-240 V 5 m No No No No
5.5-37 kW 200-240 V 25 m No No No No
0.75-7.5 kW 380-480 V 5 m No No No No
11-75 kW 380-480 V 25 m No No No No
90-800 kW 380-480 V 150 m No No No No
90-1200 kW 525-690 V 150 m No No No No
No RFI Filter installed
0.75-75 kW 525-600 V - - - - -
Table 7.4 EMC Test Results (Emission)
7.2 Immunity Requirements
The immunity requirements for frequency converters depend on the environment where they are installed. The
requirements for the industrial environment are higher than the requirements for the home and office environment. All GE
frequency converters comply with the requirements for the industrial environment and consequently comply also with the
lower requirements for home and office environment with a large safety margin.
In order to document immunity against electrical interference from electrical phenomena, the following immunity tests have
been made on a system consisting of a frequency converter (with options if relevant), a screened control cable and a
control box with potentiometer, motor cable and motor.
The tests were performed in accordance with the following basic standards:
•
EN 61000-4-2 (IEC 61000-4-2): Electrostatic discharges (ESD): Simulation of electrostatic discharges from human
beings.
•
EN 61000-4-3 (IEC 61000-4-3): Incoming electromagnetic field radiation, amplitude modulated simulation of the
effects of radar and radio communication equipment as well as mobile communications equipment.
•
EN 61000-4-4 (IEC 61000-4-4): Burst transients: Simulation of interference brought about by switching a contactor,
relay or similar devices.
•
EN 61000-4-5 (IEC 61000-4-5): Surge transients: Simulation of transients brought about e.g. by lightning that strikes
near installations.
•
EN 61000-4-6 (IEC 61000-4-6): RF Common mode: Simulation of the effect from radio-transmission equipment
joined by connection cables.
See Table 7.5.
Installation Consideration
AF-600 FP
TM
Design and Installation Guide
DET-768b 59
