GE AF-600 FP Series Design And Installation Guide

13 Specifications
13.1 Power-dependent Specifications
13.1.1 Power, Currents and Enclosures
200-240 V
HP kW A Input Efficiency IP20/Chassis IP55/Type 12 IP66/Type 4X
1 0.75 4.6 5.9 0.96
Unit size 12 Unit size 15 Unit size 15
2 1.5 7.5 6.8 0.96
3 2.2 10.6 9.5 0.96
5 3.7 16.7 15 0.96
7.5 5.5 24.2 22 0.96
10 7.5 30.8 28 0.96
Unit size 23 Unit size 21 Unit size 21
15 11 46.2 42 0.96
20 15 59.4 54 0.96
Unit size 24
Unit size 22 Unit size 22
25 18 74.8 68 0.96
Unit size 31 Unit size 31
30 22 88 80 0.96
Unit size 33
40 30 115 104 0.96
50 37 143 130 0.96
Unit size 34 Unit size 32 Unit size 32
60 45 170 154 0.96
Table 13.1 200-240 V
380-480 V
HP kW
A Input Efficiency
IP00/
Chassis
IP20/Chassis IP21/Type 1 IP54/IP55/Type 12 IP66/Type 4X
≤ 440 V
>440 V
1 0.75 2.4 2.12.7 2.7 0.96
Unit size 12 Unit size 15 Unit size 15
2 1.5 4.1 3.4 3.7 0.97
3 2.2 5.6 4.8 5 0.97
5 4.0 10 8.2 9 0.97
Unit size 12
Unit size 15 Unit size 157.5 5.5 13 11 11.7 0.97
Unit size 13
10 7.5 16 14.5 14.4 0.97
15 11 24 21 22 0.98
Unit size 23 Unit size 21 Unit size 2120 15 32 27 29 0.98
25 18 37.5 34 34 0.98
30 22 44 40 40 0.98
Unit size 24
Unit size 22 Unit size 22
40 30 61 52 55 0.98
50 37 73 65 66 0.98
Unit size 31 Unit size 31
60 45 90 80 82 0.98
Unit size 33
75 55 106 105 96 0.98
100 75 147 130 133 0.98
Unit size 34 Unit size 32 Unit size 32
125 90 177 160 161 0.98
150 110 212 190 204 0.98
Unit size 43h Unit size 41h Unit size 41h
200 132 260 240 251 0.98
250 160 315 302 304 0.98
Unit size 43h Unit size 41h Unit size 41h
300 200 395 361 381 0.98
Unit size 44h Unit size 42h Unit size 42h
350 250 480 443 463 0.98
Specifications
AF-600 FP
TM
Design and Installation Guide
