Space requirements
The following space requirements must be fulfilled at the location where the ÄKTAprocess
system will be installed:
SpecificationParameter
2050 x 2250 mmMinimum floor area for operating the
ÄKTAprocess 6 mm, 10 mm 3/8″ and 1/2″
system
(Cabinet 10)
(including 1 m of free space around the
system to allow service and mainte-
nance)
2050 x 3200 mmMinimum floor area for operating the
ÄKTAprocess 1″ SS and PP system
(Cabinet 30)
(including 1 m of free space around the
system to allow service and mainte-
nance)
Horizontal +/- 1°Floor inclination
WARNING
Access to power cord. Do not block access to the power cord. The
power cord must always be easy to disconnect.
6 ÄKTAprocess Site Preparation Guide 29-1396-55 AA
2 Site preparation overview
