Electrical requirements
SpecificationParameter
•
6 mm, 10 mm 3/8″ and 1/2″ (Cabinet
10): 100, 120, 200 to 208, 230 or 240
V AC
•
6 mm, 10 mm 3/8″ and 1/2″ (Cabinet
30): 200 to 208, 230 or 240 V AC
Supply voltage
50/60 HzFrequency
•
6 mm, 10 mm 3/8″ and 1/2″ (Cabinet
10):
-
15/16 A (100, 120 V AC)
-
10 A (200 to 208, 230 or 240 V AC)
•
6 mm, 10 mm 3/8″ and 1/2″ (Cabinet
30): 15/16 A
Minimum power supply fuse rating
1Number of wall outlets
WARNING
Protective ground. The product must always be connected to a
grounded power outlet.
The system power cord is connected in one of the following ways:
•
A fixed power supply by means of a permanent connection with a safety switch (UL
or CE classified systems)
•
A connector compliant with IEC 60309-2 (CE classified systems only)
GE does not offer a UPS (Uninterrupted Power Supply) as an accessory. How-
ever, the system is prepared for UPS operation.
Note:
The mains power supply cable is shielded ÖLFLEX™ of type:
•
CE-classified: 150CY Quattro (3 x 2.5 mm
2
)
•
UL-classified: CRF (3 x 14AWG)
If the cable needs to be replaced due to damage, the same type of cable or equivalent
must be used.
All live and neutral wiring must have a cross section area equal to or greater than the
specification in the following table:
ÄKTAprocess Site Preparation Guide 29-1396-55 AA 9
2 Site preparation overview
