AMX−4+ OPERATION
GE MEDICAL SYSTEMS (MODEL 2169360, 2236420 & 2275938 SERIES)
REV 10 om 2166913−100
1−1
SECTION 1
BEFORE YOU BEGIN
The instructions in this operation manual are for use with the AMX−4+ Mobile X−
ray Unit,
Models 2169360 2169360−2 2169360−3 2169360−4
2169360−5 2169360−6 2169360−7 2169360−8
2169360−9 2169360−10
Models 2236420 2236420−2 2236420−3 2236420−4
2236420−5 2236420−6 2236420−7
2236420−8 2236420−9 2236420−10
Models 2275938 2275938−2 2275938−3 2275938−4
2275938−5 2275938−6 2275938−7 2275938−8
2275938−9 2275938−10 2275938−12 2275938−13
2275938−14 2275938−15
Your AMX−4+ is designed for ease of operation and years of reliable service. Each
time you push a button, you can depend on the same consistent radiographic quality −
quality comparable to radiographs made in a full scale x−ray room.
ILLUSTRATION 1−1
Since the AMX−4+ is battery operated, there’s no need to plug in your mobile x−ray
unit before taking exposures. Battery operation makes the AMX−4+ easily adapted
to operating, intensive care, and emergency room applications.
Because of a dual−motor drive, driving and positioning the AMX−4+ requires a
minimum of effort. And the control panel’s cut−away design permits optimum visibil-
ity for steering down crowded corridors.
FOR TRAINING PURPOSES ONLY!
