GE b30 User Manual

B-70 B30 Bus Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
D390 ...Repeated for Remote Device 13
D394 ...Repeated for Remote Device 14
D398 ...Repeated for Remote Device 15
D39C ...Repeated for Remote Device 16
Contact Outputs (Read/Write Setting) (64 modules)
D3E0 Contact Output 1 Name --- --- --- F205 “Cont Op 1"
D3E6 Contact Output 1 Operation 0 to 4294967295 --- 1 F300 0
D3E8 Contact Output 1 Seal In 0 to 4294967295 --- 1 F300 0
D3EA Latching Output 1 Reset 0 to 4294967295 --- 1 F300 0
D3EC Contact Output 1 Events 0 to 1 --- 1 F102 1 (Enabled)
D3ED Latching Output 1 Type 0 to 1 --- 1 F090 0 (Operate-
dominant)
D3EE Reserved --- --- --- F001 0
D3EF ...Repeated for Contact Output 2
D3FE ...Repeated for Contact Output 3
D40D ...Repeated for Contact Output 4
D41C ...Repeated for Contact Output 5
D42B ...Repeated for Contact Output 6
D43A ...Repeated for Contact Output 7
D449 ...Repeated for Contact Output 8
D458 ...Repeated for Contact Output 9
D467 ...Repeated for Contact Output 10
D476 ...Repeated for Contact Output 11
D485 ...Repeated for Contact Output 12
D494 ...Repeated for Contact Output 13
D4A3 ...Repeated for Contact Output 14
D4B2 ...Repeated for Contact Output 15
D4C1 ...Repeated for Contact Output 16
D4D0 ...Repeated for Contact Output 17
D4DF ...Repeated for Contact Output 18
D4EE ...Repeated for Contact Output 19
D4FD ...Repeated for Contact Output 20
D50C ...Repeated for Contact Output 21
D51B ...Repeated for Contact Output 22
D52A ...Repeated for Contact Output 23
D539 ...Repeated for Contact Output 24
D548 ...Repeated for Contact Output 25
D557 ...Repeated for Contact Output 26
D566 ...Repeated for Contact Output 27
D575 ...Repeated for Contact Output 28
D584 ...Repeated for Contact Output 29
D593 ...Repeated for Contact Output 30
D5A2 ...Repeated for Contact Output 31
D5B1 ...Repeated for Contact Output 32
D5C0 ...Repeated for Contact Output 33
D5CF ...Repeated for Contact Output 34
D5DE ...Repeated for Contact Output 35
D5ED ...Repeated for Contact Output 36
D5FC ...Repeated for Contact Output 37
D60B ...Repeated for Contact Output 38
Table B–10: MODBUS MEMORY MAP (Sheet 62 of 64)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
