GE Multilin B30 Bus Differential System B-71
APPENDIX B B.4 MEMORY MAPPING
B
D61A ...Repeated for Contact Output 39
D629 ...Repeated for Contact Output 40
D638 ...Repeated for Contact Output 41
D647 ...Repeated for Contact Output 42
D656 ...Repeated for Contact Output 43
D665 ...Repeated for Contact Output 44
D674 ...Repeated for Contact Output 45
D683 ...Repeated for Contact Output 46
D692 ...Repeated for Contact Output 47
D6A1 ...Repeated for Contact Output 48
D6B0 ...Repeated for Contact Output 49
D6BF ...Repeated for Contact Output 50
D6CE ...Repeated for Contact Output 51
D6DD ...Repeated for Contact Output 52
D6EC ...Repeated for Contact Output 53
D6FB ...Repeated for Contact Output 54
D70A ...Repeated for Contact Output 55
D719 ...Repeated for Contact Output 56
D728 ...Repeated for Contact Output 57
D737 ...Repeated for Contact Output 58
D746 ...Repeated for Contact Output 59
D755 ...Repeated for Contact Output 60
D764 ...Repeated for Contact Output 61
D773 ...Repeated for Contact Output 62
D782 ...Repeated for Contact Output 63
D791 ...Repeated for Contact Output 64
DCmA Inputs (Read/Write Setting) (24 modules)
D7A0 DCmA Inputs 1 Function 0 to 1 --- 1 F102 0 (Disabled)
D7A1 DCmA Inputs 1 ID --- --- --- F205 “DCMA Ip 1"
D7A7 Reserved 1 (4 items) 0 to 65535 --- 1 F001 0
D7AB DCmA Inputs 1 Units --- --- --- F206 “mA”
D7AE DCmA Inputs 1 Range 0 to 6 --- 1 F173 6 (4 to 20 mA)
D7AF DCmA Inputs 1 Minimum Value -9999.999 to 9999.999 --- 0.001 F004 4000
D7B1 DCmA Inputs 1 Maximum Value -9999.999 to 9999.999 --- 0.001 F004 20000
D7B3 ...Repeated for DCmA Inputs 2
D7C6 ...Repeated for DCmA Inputs 3
D7D9 ...Repeated for DCmA Inputs 4
D7EC ...Repeated for DCmA Inputs 5
D7FF ...Repeated for DCmA Inputs 6
D812 ...Repeated for DCmA Inputs 7
D825 ...Repeated for DCmA Inputs 8
D838 ...Repeated for DCmA Inputs 9
D84B ...Repeated for DCmA Inputs 10
D85E ...Repeated for DCmA Inputs 11
D871 ...Repeated for DCmA Inputs 12
D884 ...Repeated for DCmA Inputs 13
D897 ...Repeated for DCmA Inputs 14
D8AA ...Repeated for DCmA Inputs 15
D8BD ...Repeated for DCmA Inputs 16
Table B–10: MODBUS MEMORY MAP (Sheet 63 of 64)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
