GE Multilin B30 Bus Differential System B-77
APPENDIX B B.4 MEMORY MAPPING
B
F126
ENUMERATION: NO/YES CHOICE
0 = No, 1 = Yes
F127
ENUMERATION: LATCHED OR SELF-RESETTING
0 = Latched, 1 = Self-Reset
F128
ENUMERATION: CONTACT INPUT THRESHOLD
0 = 17 V DC, 1 = 33 V DC, 2 = 84 V DC, 3 = 166 V DC
F129
ENUMERATION: FLEXLOGIC TIMER TYPE
0 = millisecond, 1 = second, 2 = minute
F131
ENUMERATION: FORCED CONTACT OUTPUT STATE
0 = Disabled, 1 = Energized, 2 = De-energized, 3 = Freeze
F133
ENUMERATION: PROGRAM STATE
0 = Not Programmed, 1 = Programmed
F134
ENUMERATION: PASS/FAIL
0 = Fail, 1 = OK, 2 = n/a
F137
ENUMERATION: USER-PROGRAMMABLE PUSHBUTTON
FUNCTION
0 = Disabled, 1 = Self-Reset, 2 = Latched
F141
ENUMERATION: SELF TEST ERRORS
941 Disconnect switch 22
942 Disconnect switch 23
943 Disconnect switch 24
968 Breaker 1
969 Breaker 2
970 Breaker 3
971 Breaker 4
972 Breaker 5
973 Breaker 6
1012 Thermal overload protection 1
1013 Thermal overload protection 2
Bitmask Element
Bitmask Error
0 Any Self Tests
1 IRIG-B Failure
2 Port 1 Offline
3 Port 2 Offline
4 Port 3 Offline
5 Port 4 Offline
6 Port 5 Offline
7 Port 6 Offline
8 RRTD Communications Failure
9 Voltage Monitor
10 FlexLogic Error Token
11 Equipment Mismatch
12 Process Bus Failure
13 Unit Not Programmed
14 System Exception
15 Latching Output Discrepancy
17 Maintenance Alert 01
18 SNTP Failure
19 Maintenance Alert
20 Maintenance Alert
21 Maintenance Alert
22 Temperature Monitor
23 Process Bus Trouble
24 Brick Trouble
25 Field RTD Trouble
26 Field TDR Trouble
27 Remote Device Offline
28 Direct Device Offline
29 Maintenance Alert
30 Any Minor Error
31 Any Major Error
33 Maintenance Alert
64 Maintenance Alert
65 IEC 61850 Data Set
66 Aggregator Error
67 Unit Not Calibrated
68 Settings Save Error
69 SRAM Data Error
70 Program Memory
71 Watchdog Error
72 Low On Memory
73 Prototype Firmware
74 Module Failure 01
75 Module Failure 02
76 Module Failure 03
77 Module Failure 04
78 Module Failure 05
79 Module Failure 06
80 Module Failure 07
